Angled Dado Jig

By: Erich Lage
Mirror-image router jigs create matching angled dadoes.

Angle dado jig drawing

Anchoring the shelves to the legs of the plant stand can be easily done with the jig you see here. It’s custom built the router bit shown in detail ‘a.’

Angle dado jig in use

Lay out dado locations along the sides of the legs as you see in main drawing above right. I made the pair of mirrored jigs you see below and employed a dado clean out bit to make the shallow dadoes for the shelves.

Angle dado jig mirror images

Published: Sept. 2, 2022
